额定载荷 Rated Capacity |
25/50/100/150/200/250 klb |
|
|
精度等级 Accuracy Class |
C3 |
|
|
灵敏度 Rated Output |
2.0±0.1mv/v |
|
|
非线性度Non-linearity |
±0.02% F.S |
|
|
蠕变 Creep（30min） |
±0.02% F.S |
|
|
输入阻抗Input Impedance |
385±10Ω |
|
|
输出阻抗Output Impedance |
351±2Ω |
|
|
工作温度Operation Temperature |
-10~+40℃ |
|
|
安全过载 Safe overload |
150%F.S |
|
|
极限过载 Destructive Load |
200%F.S |
|
|
激励电压 Excitation Recommended |
4~12VDC, Max:15vDC |
|
|
电缆结构 Cable |
4芯电缆 4-wire with screen |
Exc+(红 red)， Exc-（黑black） Sig+（绿 green），Sig-（白white） |
|
结构材质 Construction |
材质为合金钢或不锈钢 Alloy Steel or Stainless steel, IP67 |
|
|
适用场合 Application for |
各种吊秤和拉力测试场合 Crane,packing scale,tension etc. |
|
